Industrial Oil Cooling Chiller systems are designed to control excess heat in hydraulic and lubrication oil, ensuring optimal machine performance and protecting critical components from damage.It circulates chilled oil or employs a heat exchange system to have constant temperature when the machine is in continuous operation. This assists in enhancing machine efficiency, wear reduction and long life cycle of pumps, motors and bearings.
Industrial Oil Cooling Chillers are typically used in CNC machines, presses, injection molding machines, compressors and heavy-duty production machines. It has dependable compressors, effective heat exchangers and simple control mechanisms, which provide constant cooling at minimal power consumption. The chiller makes sure that the required oil temperature is maintained, so that operations are flowing smoothly, there are less downtimes and output is maintained in heavy industrial settings.
Aquatech Plus is one of the topmost Indian-based Industrial Oil Cooling Chillers Manufacturers in India, which deals in rugged and high-performance coolers in order to keep the hydraulic and lubricating oils at the right temperature in heavy industrial machines. We design our industrial oil cooling chillers to deliver high-precision cooling, consistent operation, and professional service, even within the industrial environment.
CNC machining, injection molding, hydraulic pressing, and metal processing generate large amounts of heat, even during continuous operation. Aquatech Plus oil chillers will effectively eliminate surplus heat, ensuring oil and machines remain undamaged and preventing production errors. Our ISO 9001:2015 certified production, in-house engineering skills, and stringent quality management enable us to provide individualized oil chillers that cater to a wide range of industrial needs.
An industrial oil cooling chiller, also known as a special refrigeration unit, is a refrigerator constructed to control and stabilize the temperature of the hydraulic, lubricating, and process oils in industrial machinery. The chillers facilitate oil staying within a constant temperature of 25°C to 40°C, which is important in maintaining the right viscosity, lubrication performance, and machine precision.
Oil cooling chillers are particularly used in industries with exacting applications, such as those requiring high accuracy, continuous loads, and demanding operating conditions; general-purpose chillers are not designed for these factors.
Oil transfers heat produced by motors, pumps, and the workings of the machine during constant machine operation. Unless this heat is properly dissipated, then oil temperature increases, resulting in:
This leads to a decrease in the viscosity of the oil, a process known as oil thinning
Hydraulic systems: Internal leakage.
Marshmallow: Thus, machining accuracy is influenced by a process known as thermal expansion.
An industrial oil cooling chiller removes this excess heat to keep the oil temperature within a constrained range. This guarantees steady machine performance, increased product quality, increased oil life, and decreased downtime, and thus oil chillers are very essential in the contemporary industrial work.
Aquatech Plus produces different specifications of oil cooling chillers to suit different operational requirements:
In such systems oil will be cooled by pumping continuously through a heat exchanger within the chiller and sent back to the machine. They are best suited for the applications of high-flow and continuous-duty, which need a constant oil temperature.
In immersion chillers, the coil of the evaporator is simply lowered into the reservoir or oil tank. An internal agitator is provided to ensure even cooling in the sump. These chillers are characterized by easy installation, good cooling, and easy maintenance.
Air-cooled oil chillers reject heat in ambient air by using condenser coils and fans. Their installation is relatively easy, and they can be used in an industry where there is a limited water supply or even limited water quality.
Water-cooled chillers disperse heat with an external source of water, say a cooling tower. They are also more energy efficient where a large capacity or a large amount of heat load is involved, but a separate water system is required.
Industries provide Aquatech Plus oil cooling chillers, designed to be durable, accurate, and safe.
Aquatech Plus Private Limited is known as a trusted Industrial Oil Cooling Chiller Suppliers in India that provides efficient and high-quality cooling services to industries. Chillers are also tested according to high standards of quality to guarantee reliable long-life performance.
The processes are ISO-Certified manufacturing
Industrial oil cooling chillers use the vapor compression style of refrigeration. The machine’s hot oil is taken through the oil-to-refrigerant heat exchanger, where the heat is absorbed. Refrigerant pressure is then elevated by the compressor, and the heat is rejected by air-cooled or water-cooled condensers.
The sophisticated control systems continually detect the oil temperature and regulate the cooling capacity to sustain constant operating conditions and provide effective and efficient cooling output.
In most industries, industrial oil cooling chillers are required in various sectors, such as:
Aquatech Plus maintains a robust and growing network of Industrial Oil Cooling Chiller Dealers in India, which ensures the timely delivery of products and the local support of the company in the industrial zones. Our dealers are trained to offer technical support, system choice service, installation services, and immediate after-sales services.
Through the close partnership with our dealer partners, we make sure that we deliver on-time, authentic spare parts and provide consistent after-sales services to end users. The availability of such a nationwide dealer base allows the industries to continue their operations without interruption and their oil cooling systems to reliably work in the long term.
Aquatech Plus is also a reliable Industrial Oil Cooling Chiller Exporters in India, and it offers quality oil cooling to the international markets. We produce our chillers to meet global quality standards and engineer them to operate under various climatic and industrial conditions.
We guarantee safe and timely delivery all over the world with excellent packaging, extensive testing, and export documentation. We are providing export solutions to varied sectors and have tailor-made designs, affordable pricing, and reliable technical support for our international customers.
Aquatech Plus provides high-performance, durable, and precision-engineered industrial oil cooling chillers that guard the machinery, enhance productivity, and ensure long-term stable operation. You may require a 1 TR oil chiller for a CNC machine or a high-capacity system for large hydraulic operations of hydraulic; our solutions are fit to suit your needs.
Call Aquatech Plus now and get professional advice on the right approach, a tailor-made oil cooling system, and reliable post-sales care.
| Item | Model | FC-0.2AO | FC-0.5AO | FC-0.8AO | FC-1AO | FC-1.5AO | FC-2AO | FC-3AO | FC-4AO | FC-5AO | FC-6AO |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Cooling Capacity | Kcal/h (50Hz) | 843 | 1419 | 1703 | 2451 | 3139 | 4859 | 7568 | 9890 | 12470 | 14448 |
| Kcal/h (60Hz) | 1011 | 1703 | 2043 | 2941 | 3767 | 5831 | 9082 | 11868 | 14964 | 17338 | |
| KW (50Hz) | 0.98 | 1.65 | 1.98 | 2.85 | 3.65 | 5.65 | 8.2 | 11.5 | 14.5 | 16.8 | |
| KW (60Hz) | 1.2 | 2 | 2.4 | 3.4 | 4.4 | 6.8 | 10.6 | 13.8 | 17.4 | 20.2 | |
| Input Power | KW | 0.64 | 0.84 | 1 | 1.39 | 1.72 | 2.65 | 3.68 | 5.93 | 7.2 | 9.4 |
| Power Source | 3PH ~ 220V / 380V / 415V / 480V ~ 50Hz / 60Hz | ||||||||||
| Refrigerant | Type | R22 / R407C / R134a / R404A / R410A | |||||||||
| Control | Thermostatic Expansion Valve | ||||||||||
| Compressor | Type | Hermetic Scroll (Piston) | |||||||||
| Power (KW) | 0.4 | 0.55 | 0.68 | 0.89 | 1.2 | 1.75 | 2.7 | 3.5 | 4.55 | 5.25 | |
| Condenser | Type | Efficient finned copper tube with aluminum + low noise air blower | |||||||||
| Air Blower (KW) | 0.05 | 0.1 | 0.13 | 0.13 | 0.15 | 0.15 | 0.23 | 0.23 | 0.42 | 0.42 | |
| Evaporator | Type | SS Tank Coil / Shell & Tube / Plate Type Heat Exchanger | |||||||||
| Pipe Connection | 1/4" | 1/2" | 1/2" | 3/4" | 3/4" | 3/4" | 1" | 1" | 1-1/4" | 1-1/4" | |
| Oil Pump | Power (KW) | 0.19 | 0.19 | 0.19 | 0.37 | 0.37 | 0.75 | 0.75 | 2.2 | 2.2 | 3.75 |
| Flow (m³/h) | 0.24 | 0.33 | 0.33 | 1.5 | 1.5 | 2.4 | 2.4 | 3.9 | 4.5 | 5.4 | |
| Pressure | Kgf/cm² (Max) | 3 | |||||||||
| Oil Viscosity Range | 0.5 – 300 CST (Hydraulic oil, lubricating oil) | ||||||||||
| Oil Tank | L | 8 | 18 | 18 | 22 | 22 | 33 | 38 | 95 | 95 | 95 |
| Safety Devices | Compressor inner protection, over current protection, high/low pressure protection, over temperature protection, phase sequence/phase missing protection, anti-freezing protection, exhaust overheat protection. | ||||||||||
| Dimensions | With Tank - L (mm) | 460 | 460 | 460 | 570 | 570 | 620 | 620 | 850 | 850 | 950 |
| With Tank - W (mm) | 325 | 325 | 325 | 430 | 430 | 600 | 635 | 800 | 800 | 800 | |
| With Tank - H (mm) | 680 | 920 | 1050 | 1200 | 1200 | 1280 | 1420 | 1450 | 1450 | 1620 | |
| Without Tank - L (mm) | 460 | 460 | 460 | 570 | 570 | 620 | 620 | 850 | 850 | 950 | |
| Without Tank - W (mm) | 325 | 325 | 325 | 430 | 430 | 600 | 635 | 800 | 800 | 800 | |
| Without Tank - H (mm) | 680 | 720 | 850 | 1010 | 1010 | 1090 | 1230 | 1250 | 1250 | 1450 | |
| Weight (KG) | With Tank | 38 | 55 | 75 | 92 | 95 | 145 | 165 | 235 | 243 | 276 |
| Without Tank | 36 | 51 | 68 | 76 | 79 | 132 | 153 | 210 | 223 | 245 | |
| Note: Chilled oil inlet/outlet temperature: 20°C / 45°C. Cooling air inlet/outlet temperature: 30°C / 40°C. Specifications are subject to change without prior notice. |
|||||||||||
We have a uniform workflow in packaging and logistics that is export-wise, which prepares all our products except that they are safe in handling and delivery with no damages in India and other countries. Every phase is also thought out to cushion equipment against vibration, impact, and moisture risks in addition to long-distance transportation risks. The same is done to water chillers, air chillers and all other products that we produce and supply.
The process starts with mechanical repair of the unit of the product. The industrial quality fastening is used in all internal assemblies, critical parts, piping, and electrical parts. Moving components are fixed, and vibration-sensitive sites are fixed to avoid the mechanical stress during the transportation.
Objective: Avoid internal movement, vibration breakage, and alignments during transportation.
Once the repair is done the product is inner-packed with moisture-proof and shock absorbing materials. Foam padding, stretch film and cushioning materials are used as protective layers to cover all the exposed areas and all those components which are sensitive.
Objective: Dust, humidity, surface abrasion, and small mechanical shocks.
The product is packed in a specially designed heavy-duty plyboard box which is produced depending on its size and weight. The casing of the plywood is strengthened to resist the weights of the stacking, forklift operation and the transportation strain over long distances. When exporting goods, the packing is done to comply with the shipping and container loading requirements by the international community.
Objective: Optimal security on the outside and the requirements of the domestic and export logistics.
The product is loaded to the trucks with the use of cranes or forklifts, in accordance with good lifting and load-sharing practices. The delivery is then by road under conditions of control. In the case of domestic clients, the truck will go straight to the facility of the customer.
Objective: Loading and stable transportation on the road.
Whereas in international deliveries, the shipment is taken out of our plant to the Indian port. Pre-port entry All the export documentation, labeling and compliance checks are done before port entry.
Our logistics partners are reputable and trusted individuals like EMS, DHL Express, and FedEx Express who help us to have an easy time moving the ports and handling the exports.
Goal: The port handling and export preparation are smooth.
After clearance in the port, the product is delivered through sea freight into the destination port of the client. The packaging is to maintain a long transit period, container handling and a fluctuating weather pattern.
The international deliveries are also arranged with the help of the existing world logistics systems, the EMS, DHL Express and FedEx Express, which guarantee the safe and timely delivery.
Purpose: Achieve international delivery with low levels of transits.
A clear packaging and transportation procedure would assure that all products will be delivered to the clients in working conditions, lessen installation and commission problems, minimize the risk of transit damage, and facilitate hassle-free domestic and foreign delivery.
This is our standard operating procedure and is used in the process of packaging and transportation of all our products. Although the central process is the same, a different method can be used to pack the products, depending on the product size, weight and the destination to which the product is to be shipped.
This packaging and transportation workflow represents our standard operating process and is uniformly followed across our entire product range. The steps outlined above are not product-specific but define our company-wide logistics and export handling standards.
To maintain consistency, safety, and compliance, this process is intentionally displayed across all relevant product pages under the Packaging & Transportation section. While the framework remains the same, actual packing materials, box dimensions, and handling methods may vary depending on product size, weight, and shipment destination.
From an operational standpoint, this approach ensures:
From an SEO and documentation perspective, this section is used to clearly communicate our established logistics protocol, not to repeat marketing content. Each product page focuses on its unique specifications and applications, while this section defines our common logistics standards.
When machines are used in the industry, they produce a lot of heat. An oil chiller maintains stable temperature of oil, prevents overheating, wear and tear, and prolongs the life of a machine.
Aquatech Plus oil chillers have the ability to run hydraulic oil, lubricating oil, transformer oil as well as other industrial-grade oils, which makes the cooling safe and efficient.
Yes. Our chillers are set to operate 24/7 and ensure constant cooling 24/7 without interruptions and therefore they are suitable in the high-demanding industrial environment.
Select according to the rate of the oil flow, amount of heat load and the operating temperature range. Aquatech Plus professionals could help you to choose a model that can suit your machinery and process needs.
Oil cooling prevents overheating of hydraulic and lubricating oil, maintains proper viscosity, protects machine components, and ensures consistent performance during continuous heavy-duty industrial operations.
By maintaining stable oil temperature, the chiller reduces thermal stress, minimizes wear on seals and components, and helps extend machinery lifespan while improving overall operating reliability.
We carry a specified warranty and effective after sales services to all goods provided by us. Our warranty and service system will be aimed at long-term performance, reliability in terms of work, and peace of mind of our clients, both domestic and international.
Every product has a standard warranty of manufacturing defects dating back to the dispatch date or the date of installation, as existing. The warranty includes the defects to the quality of material and workmanship in the normal operation condition.
There are various warranty terms based on the product category, model, application and environment of use. Specifics on warranty period and coverage are provided in detail during the confirmation of orders or issue of invoice.
Warranty is not applicable on damages caused by:
Our technical support provides our clients with instructions on how to install, answer technical questions as well as basic troubleshooting. Depending on where the project is located, support is accomplished by providing documentation, remote assistance or by organizing services with service partners.
We assist both domestic and foreign clients with well-organized contact and export documentation. In the case of international customers, technical support and service management are offered remotely to have a comfortable functioning and prompt problem resolution.
There is a process in which service requests are processed. When we get a support request, we examine the problem and determine the warranty eligibility and suggest a remedy. The response timelines can be different depending on the product, location and availability of the components.
The above warranty and support terms are the standard policy which we use in our whole product line. Particular product-level warranty information might vary and are provided independently when taking orders.
This Warranty & Support section represents our standard company-wide policy and is consistently applied across our complete product range. The content is intentionally displayed on multiple product pages to communicate uniform warranty coverage, service terms, and support procedures.
While the core policy remains the same, actual warranty duration, coverage scope, and service conditions may vary by product model, application, and operating environment. Product-specific warranty details are shared separately at the time of order confirmation or documentation.
>
>
>
>
